LS Tractor MT774CPS Utility Tractors
Call for Price
Overview
Specifications
engine
drive train
pto
hydraulic system
dimension
tire size
options
literature
- 24F x 24R Power Shuttle
- Standard Air Suspension Seat
- Standard Electric Engaged Independent PTO
- Standard Instructor Seat
- Standard Interior Power Source
- Optional Third Rear Remote
Model
MT774CPS Utility Tractors
Category Name
Tractors
Year
2026
Sale Type
New
Manufacturer
LS Tractor
Total Weight Without Ballast (lbs.)
7,827
Type
4 Cylinder, CRDI, Water-cooled
PTO HP
65.6
Model (Tier 4 )
F34
Engine HP (Gross)
73.7
Rated Speed (RPM)
2,200
Displacement (cu In.)
206.7
Fuel Tank Capacity (gal)
30.4
Brakes
Wet, Multi – disc
No. Of Speeds
24 X 24
Transmission Type
Power Shuttle
Forward Speed (mph)
0.9 – 20.8
Type
Independent
Rear, Rpm
540 / 750 / 1,000
Remote Valves
3 pairs (Front), 2 pairs (Rear)
Control System
Position/Draft
Total Flow (gpm)
22.2
Steering Pump (gpm)
6.5
Category, 3 Pt Hitch
CAT II
Implement Pump (gpm)
15.7
Hitch Lift Capacity, Lbs (Hitch End)
7,275
Wheelbase (in.)
90
Height To Top (in.)
105
Min. Overall Width With Tires (in.)
78.7
Overall Length (Frame To Link, In.)
152.2
Front / Rear Ag
F: 13.6-24, R: 18.4-34
Front / Rear R14
FW: 340/70R28, RR: 460/75R38
Literature
| Name | Link |
| LS Model Comparison | Download |
