LS Tractor MT240HE Compact Tractors
Call for Price
Overview
Specifications
engine
drive train
pto
hydraulic system
dimension
tire size
options
literature
- 4WD (Front Wheel Mechanical Assist) – Go from 2WD to a 4WD with a simple move of a lever.
- Independent PTO – Easiest PTO to operate that can be turned on or off with a switch.
- Dual Pedal, 3 Range HST – Easier and more comfortable than rocker pedals. Includes cruise control.
- Standard Tilt & Power Steering – Makes turning easier, improves control and reduces fatigue.
- Fender Mounted Joystick For Front End Loader – Easily accessible for maximum comfort and convenience.
- Standard Foldable ROPS – Allows Storage in low clearance buildings or sheds.
- Your Choice Of Tires At No Additional Cost – Choose Ag, Industrial or Turf tires at no additional cost. *Subject to dealer inventory.
- 3-Point Hitch – Category 1 with a hitch lift capacity of 1,808 lbs. allows usage of a wide variety of implements.
- Ergonomically Designed 3-Point Hitch Controls – Easily accessible for maximum comfort and convenience with hydraulic position control.
- Standard Draw Bar – Increases the usefulness of the tractor without the additional optional cost.
- Large Fuel Tank – 7.4 gallon capacity provides long operation times between fill ups.
- Standard Rubber Mat – Reduces noise, vibration and prevents slipping.
- LS CRDI Tier 4 Engine – Generates more power with less noise, fuel consumption, vibration and emissions. Standard preheat starting aid helps starting in cold weather.
- Easy Open One-Piece Hood – Easy access for maintenance of this low emissions, fuel efficient engine. Standard pre-heat starting aid improves starting in cold weather.
- Modern Ergonomic Design – This compact is ergonomically designed.
- Adjustable Seat With Seat Belt – Keeps you in a comfortable and safe position for maximum control.
Model
MT240HE Compact Tractors
Category Name
Tractors
Year
2026
Sale Type
New
Manufacturer
LS Tractor
Total Weight Without Ballast (lbs.)
2,884
Type
3-Cylinder, CRDI, Water-cooled, Diesel, TC
PTO HP
32
Model (Tier 4 )
L3C19-T
Alternator (V-A)
12V – 70 Amps
Engine HP (Gross)
40
Rated Speed (RPM)
2,600
Displacement (cu In.)
114.7
Fuel Tank Capacity (gal)
7.4
Brakes
Wet, Multi-disc
Steering
Hydrostatic Power Steering
No. Of Speeds
3 Ranges (HST)
Transmission Type
HST
Type
Independent
Rear, Rpm
540 (Standard)
Mid PTO, Rpm
2000 (Field Option)
Remote Valves
Manual
Control System
Position
Total Flow (gpm)
13.7 (HST)
Steering Pump (gpm)
5.5 (HST)
Category, 3 Pt Hitch
CAT I
Implement Pump (gpm)
8.2
Hitch Lift Capacity, Lbs (Hitch End)
1,808
Wheelbase (in.)
69
Height To Top (in.)
86.6
Overall Length (Frame To Link, In.)
128.3
Ag Front / Rear
7 – 14 / 11.2 – 24
IND Front / Rear
25 x 8.5 – 14 / 43 x 16 – 20
Turf Front / Rear
25 x 8.5 – 14 / 43 x 14 – 20
