LS Tractor MT342H/HC/C Compact Tractors
Call for Price
Overview
Specifications
engine
drive train
pto
hydraulic system
dimension
tire size
options
literature
- 4WD (Front Wheel Mechanical Assist) – Go from 2WD to a 4WD with a simple move of a lever.
- Independent PTO – Easiest PTO to operate that can be turned on or off with a switch.
- Standard 12×12 Synchro Shuttle – Change gears without having to stop. 12 forward / 12 reverse gear transmission provides more operating speeds than others in its class for superior control, precision and safe operations for virtually any application.
- Side Mounted Main Gear Lever – Maximizes space and makes getting on and off tractor easier than straddle type like other brands.
- Standard 2 Sets Of Remote Valves With Detent – Adds functionality and improves ease of use by allowing attachment of hydraulically controlled implements without the high, additional costs like others in its class to add the remotes as options.
- Extendable Lower Links – Allows easier attachment of a wide variety of Category 1 implements with a 1,808 lb lift capacity.
- Standard Tilt & Power Steering – Makes turning easier, improves control and reduces fatigue.
- Fender Mounted Joystick For Front End Loader – Easily accessible for maximum comfort and convenience.
- Standard Foldable ROPS – Allows Storage in low clearance buildings or sheds.
- Your Choice Of Tires At No Additional Cost – Choose Ag, Industrial or Turf tires at no additional cost. *Subject to dealer inventory.
- 3-Point Hitch – Category 1 with a hitch lift capacity of 1,808 lbs. allows usage of a wide variety of implements.
- Standard Hydraulic Position And Draft Control – Easily accessible for maximum comfort and convenience.
- Standard Rear Work Light – Adjustable light to improve visibility where you need it.
- Standard Draw Bar – Increases the usefulness of the tractor without the additional optional cost.
- 7 Pin Connector – Provides electrical Power for implements when needed.
- Large Fuel Tank – Provides long operation times between fill ups.
- Flat Platform And Rubber Mat – Roomy, spacious and comfortable.
- LS CRDI Tier 4 Engine – Generates more power with less noise, fuel consumption, vibration and emissions. Standard preheat starting aid helps starting in cold weather.
- Easy Open One-Piece Hood – Easy access for maintenance of this low emissions, fuel efficient engine. Standard pre-heat starting aid improves starting in cold weather.
- Modern Ergonomic Design – This compact is ergonomically designed.
- Deluxe Adjustable Seat With Arm Rests And Retractable Seat Belt – Keeps you in a comfortable and safe position for maximum control.
Model
MT342H/HC/C Compact Tractors
Category Name
Tractors
Year
2026
Sale Type
New
Manufacturer
LS Tractor
Total Weight Without Ballast (lbs.)
3,935 – 4,446(CAB)
Type
3-Cylinder, liquid-cooled, Diesel, TC, CRDI
PTO HP
35.7 Hydr / 33.6 Gear
Model (Tier 4 )
L3C19-T
Alternator (V-A)
12V – 70 Amps
Engine HP (Gross)
42
Rated Speed (RPM)
2,600
Displacement (cu In.)
114.7
Fuel Tank Capacity (gal)
12.4 (CABIN) / 10.6 (ROPS)
Brakes
Wet, Multi-disc
Steering
Hydrostatic Power Steering
No. Of Speeds
F16 x R16(GEAR) / 3 Ranges(HST)
Transmission Type
Synchro shuttle / HST
Type
Independent
Rear, Rpm
540 (Standard)
Remote Valves
2 Pairs (Front), 2 Pairs (Rear) (Detent, Standard)
Control System
Position / Draft
Total Flow (gpm)
12.3 Gear /13.7 Hydro / 15.0 Hydro Cab
Steering Pump (gpm)
4.1 Gear / 5.5 Hydro / 6.8 Hydro Cab
Category, 3 Pt Hitch
CAT I
Implement Pump (gpm)
8.2
Hitch Lift Capacity, Lbs (Hitch End)
2,755
Wheelbase (in.)
73.2
Height To Top (in.)
95 ROPS / 90 Cab
Overall Length (Frame To Link, In.)
133
Ag Front / Rear
9.5 – 16 / 13.6 – 24
IND Front / Rear
12 – 16.5 / 17.5L – 24
Turf Front / Rear
28 x 8.5 – 15 / 41 x 14 – 20
Literature
| Name | Link |
| LS Model Comparison | Download |
