ID # 19294169

LS Tractor MT7101CSPS – 100.6HP

Name: LS Tractor MT7101CSPS – 100.6HP
Brand: LS Tractor
Availability: InStock

Call for Price

Get a Quote Get Financed Value a Trade Book a Demo Get Directions Get Directions Print

Overview

Utility

Our top-of-the-line MT7 Semi-Powershift Series is available with 101 horsepower and includes an ergonomic and spacious cab. Premium features such as a standard instructor’s seat, Goodyear LSW tires, two rear remotes, and superior lift capacities for both the front-loader and three-point hitch come standard.

Specifications

Model

MT7101CSPS – 100.6HP

Year

2022

Sale Type

New

Manufacturer

LS Tractor

PTO HP

85.5 HP

ENGINE HP

100.6 HP

HITCH LIFT

8,378 lbs.

LOADER LIFT CAPACITY

5,139 lbs.

features

HIGH CAPACITY LOADER

High Performing Lift Capacity, Among The Industry Leaders In Lift Height (139.9 in.) LS Tractor MT7101CSPS – 100.6HP

GOODYEAR LSW TIRES

Enable Better Traction, Less Field Compaction LS Tractor MT7101CSPS – 100.6HP

SPACIOUS CAB

Providing a Roomy Climate Controlled Working Environment LS Tractor MT7101CSPS – 100.6HP

STANDARD FACTORY GRILLE GUARD W/LOADER

Full Length Grille Guard Protects Body Panels And Radiator LS Tractor MT7101CSPS – 100.6HP

DURABILITY AND CAPACITY

Heavy-Duty Frame And Lift Cylinders Enable Three-Point Lift Capacity Up To 5,139 lbs. LS Tractor MT7101CSPS – 100.6HP

SEMI-POWERSHIFT WITH POWER SHUTTLE TRANSMISSION

Provides Efficiency And Comfort In Demanding Applications (Standard) LS Tractor MT7101CSPS – 100.6HP

RIGHT-SIDE CAB ACCESS

Enables Operators To Access Both Sides Of The Cab (Door And Steps) LS Tractor MT7101CSPS – 100.6HP

FOUR STANDARD REAR WORKLIGHTS

Provides Significant Illumination During Night Operation LS Tractor MT7101CSPS – 100.6HP

ERGONOMIC DESIGN

Provide Access To Controls For A Variety Of Applications LS Tractor MT7101CSPS – 100.6HP

specifications

ENGINE

Type: 4 Cylinder, CRDI, Water-cooled
Model: F5G
Emission: Tier 4 Final
Engine HP (Gross): 100.6
PTO HP: 85.5
Rated Speed (RPM): 2,200
Displacement (cu. in): 206.7
Fuel Tank Capacity (gal): 30.4

DRIVE TRAIN

Transmission Type (Option): Semi-Powershift with Power Shuttle
No. of Speed: 32 X 32
Forward Speed (mph): 0.1 – 22.6

PTO

Type: Independent / Ground Speed PTO
Rear, rpm: 540 / 750 / 1,000

HYDRAULIC SYSTEM

Control System: Position/Draft
Implement pump (gpm): 15.7
Steering pump (gpm): 6.5
Total flow (gpm): 22.2
Category, 3 pt hitch: CAT II
Hitch Lift capacity, lbs (Hitch end): 8,278
Remote Valves: 3 pairs (Front), 2 pairs (Rear)

DIMENSION

Overall length (Frame to Link, in.): 152.2
Overall width with tires (in.): 78.7
Wheelbase (in.): 90
Height to top (in.): 105.4

TIRE SIZE

Front / Rear R14: FW: 340/70R28, RR: 460/75R38
Front / Rear Ag: F: 13.6-24, R: 18.4-34

WEIGHT

Total weight without ballast (lbs.): 7,714

options

Remote Valve- 1 pair (2 outlets) or 2 pair (4 outlets)
Work Light
Rear work lamp
Horn
7 pin electrical connector

attachments

FRONT LOADER – LL8100

Bucker Size (in): 83
Maximum Lift height (in): 139.9
Clearance with Attachment Dump (in): 103.3
Reach at Maximum Height (in):23.4
Maximum Dump Angle (deg.) 57
Maximum Rollback Angle (deg.): 46
Digging Depth (in): 4.6
Overall Height in Carry Position (in): 68.8
Lift Capacity(@ Pivot pin) (lbs.) 5,139
Breakout Force(@ Pivot pin) (lbs.): 5,313
Approx. Weight(Loader w/o Bucket)(lbs.): 1,660
