Zetor Major CL 80 |
|||||||||||||||||
Specifications
|
|||||||||||||||||
Description
|
|||||||||||||||||
FEATURES
|
|||||||||||||||||
Features
|
|||||||||||||||||
ENGINE
|
|||||||||||||||||
Type
Deutz TCD 2.9 L4 Stage V
Max._torque
300.0 Nm
Rated_speed
2,200 rpm
Torque_rise
25%
Displacement
2,925 cm3
Engine_design
Diesel, direct fuel injection, common rail, turbocharged, DOC filter, DPF filter
,Rated_power_(ECE_R120)
55.4 kw,75.3 HP
No._of_cylinders_/_valves
4/8
|
|||||||||||||||||
TRANSMISSION
|
|||||||||||||||||
Type
4 mechanical gears with 3 ranges
Reverser
Mechanical (SynchroShuttle)
Max._speed
30 km/h
Number_of_gears_(F/R)
12/12
|
|||||||||||||||||
PTO
|
|||||||||||||||||
Type
Independent / ground speed
Control
Mechanical
Rear_PTO_Revolutions
540/1,000 rpm
|
|||||||||||||||||
HYDRAULICS
|
|||||||||||||||||
Type
Mechanical with regulation
Gear_pump_capacity
50 l/min
Rear_hydraulic_remotes_(Quickcouplers)
2+1 / 4+1 (OPT)
|
|||||||||||||||||
THREE-POINT HITCH
|
|||||||||||||||||
Type
Category II
Max._lift_capacity
18 kN
Lifting_capacity_in_full_range
15 kN
|
|||||||||||||||||
CAB
|
|||||||||||||||||
Driver's_seat
Mechanically suspended STANDARD seat with safety belt / Pneumatic suspension OPT
Steering_wheel
Fixed / Tiltable, height adjustable OPT
Heating_/_Air-Conditioning
Standard / OPT
|
|||||||||||||||||
UNDERCARRIAGE
|
|||||||||||||||||
Fuel_tank
80 L
Drive_System
4WD
Front_mudguards
Fixed
Operating_brakes
Mechanical with connecting the front axle
|
|||||||||||||||||
OTHER SPECIFICATION
|
|||||||||||||||||
Wheelbase
2,210 mm
Operating_weight_1
2,960 - 3,645 kg
Length_/_Width_/_Height_min.
3,505 / 1,941 / 2,560 mm
Length_*_/_Width_**_/_Height_max.
4,511 / 2,241 / 2,586 mm
Max._technically_permissible_weight
4,300 kg
|
