Jaylor 5850 TMR Twin Auger

Videos
Call for Price
Overview

Jaylor 5000 Series Twin Auger TMR mixers are available in a wide range of configurations from 615 to 960 cubic feet (ft3). These machines specialize in feeding larger dairy and cow-calf operations, along with feedlots ranging in size from as little as a hundred head, up to thousands of head. Each one is an industry leader in its class, processing round or square baled hay and baleage into uniform rations. Jaylor’s patented square augers create a unique TMR, disrupting the cattle’s natural feeding tendencies of sorting their ration. Giving you true control of what your cattle eat.

All of our Twin Auger Mixers are ideal for mixing pre-processed silage and grain rations. This includes high-grain finishing rations, achieving a fully uniform mix in as little as 3 to 5 minutes.

The “Low Profile” 5600 is capable of being used with skid-steer loaders, where loading heights are limited. All these mixers come standard with patented square-cut Jaylor augers and a full range of innovations, warranties, and options to create your tailored feeding solution.

Specifications
Model
5850 TMR Twin Auger
Year
2024
Sale Type
New
Manufacturer
Jaylor
features
  • 3 Point Weight System
  • Rapid Discharge Door
  • Galvanized Discharge Conveyor
  • Sloped Top Square Cut Augers
  • Tungsten Carbide Coated Knives
  • Welded Mixing Chamber
  • Structurally Reinforced Frame
  • Shear Bolt Protection
  • Mixer Viewing Window
  • Restrictor Blades (2)
  • Adjustable Cast Hitch
  • Heavy Duty Planetary Gearbox
  • Patented Open Loop Oil Reservoir
  • Central Greasing Bank
  • Shaker Box
specifications

5850 TMR Twin Auger
Capacity No Extension 800ft³ | 22.7m³
Capacity 8" Extension 865ft³ | 24.5m³
Capacity 12" Extension 910ft³ | 25.8m³
Capacity 16" Extension 960ft³ | 27.2m³
Weight 13500lbs | 6100kg
Height 108in | 274cm
Length 308in | 782cm
Drum Width 97in | 246cm
Pto Speed 1000 RPM
Minimum Hp 125 HP
Auger Speed 38 RPM
Number Of Knives 18
Auger Flighting Thickness 5/8in | 16mm
Max Discharge Height 60in | 152cm
Conveyor Width 36in | 91cm
Door Opening Width 42in | 107cm
Floor Thickness 5/8in | 16mm
Drum Wall Thickness 1/4in | 6mm
Standard Tires 15.0/55-17 26 PLY (4)
Wheel Assembly Dual Oscillating
